Excavator Hydraulic Breaker Rock Hammer Breaker Mining High-frequency Vibration Hydraulic Breaker
Model DSB2200
Overview
Excavator Hydraulic Breaker Rock Hammer Breaker Mining High-frequency Vibration Hydraulic Breaker supplied by DONSANG Machinery Co., Ltd. Key published specifications: Certification CE,ISO9001; Model Open Type; Operation Pressure 160~180 Kgf/cm2; Oil Flow 120~150 L/min. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Certification | CE,ISO9001 |
|---|---|
| Model | Open Type |
| Operation Pressure | 160~180 Kgf/cm2 |
| Oil Flow | 120~150 L/min |
| Impact Rate | 350~500 Bpm |
| Nitrogen | 6~8 Bar |
| Chisel Diameter | 135 Mm |
| Chisel Length | 1250 Mm |
| Chisel Weight | 121 Kg |
| Hose Size | PF1'' Inch |
| Noise Level | 16-22 M |
| Suitable Excavator | 20~26 Ton |
| Impact Force | 3450 J |
| Total Length | 2719 Mm |
| Operation Weight | 1784 Mm |
