Earth series wide belt feeder
Model ASEA1
Overview
Earth series wide belt feeder supplied by Shenzhen KHJ Technology Co., Ltd. Listed under Feeders. Key published specifications: Weight 75kg; Width range 8mm-44mm; Thickness 0.2mm-1.m; Pocket height ≤10mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Weight | 75kg |
|---|---|
| Width range | 8mm-44mm |
| Thickness | 0.2mm-1.m |
| Pocket height | ≤10mm |
| Splicing length | 160mm |
| Front clip | Frame type,20PCS/frame |
| Back clip | Rolly Tpe,Core ID 1.5 inches,1000PCS/Roll |
| Misalignment accuracy | ±0.15mm |
| Winding Device | One set(left side) |
| Carrier tape Reel | 7inches,13inches,15inches |
| Battery voltage | 48V |
| Charging voltage | 100V-220V |
| Charging time | 8H |
| Full Charge Working Time | 12-14H |
| Winding Speed | 300rpm |
| MES | Available as Option |
| Barcode Gun | Available as Option |
| Right Receving Arm | Available as Option |
