Overview

DN100 Class 300 310S Metal Seal Heat Sink High-Temperature Ball Valve supplied by TIANYU VALVE. Listed under Ball Valves. Key published specifications: Size Range DN50 ~ DN300; Pressure Range Class 150 ~ 600; Temperature Range -30°C ~ +800°C; Design Standards API 6D, ASME B16.34, ISO 10497. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Size Range	DN50 ~ DN300
Pressure Range	Class 150 ~ 600
Temperature Range	-30°C ~ +800°C
Design Standards	API 6D, ASME B16.34, ISO 10497
Seal Type	Metal-to-metal (ANSI/FCI Class V)
End Connections	Flanged (RF/RTJ)
Certifications	API 6D compliant
