CultivatorFS550-21
Overview
CultivatorFS550-21 supplied by XUANHUA CONSTRUCTION MACHINERY DEVELOPMENT CO., LTD. Key published specifications: Dimension(Lengh*Width*Hight) 5240X2100X2400（mm）; Operating weight 11600 Kg; Fuel tank capacity 440L; Hydraulic oil tank capacity 280 L. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Dimension(Lengh*Width*Hight) | 5240X2100X2400（mm） |
|---|---|
| Operating weight | 11600 Kg |
| Fuel tank capacity | 440L |
| Hydraulic oil tank capacity | 280 L |
| Ground clearance | 350mm |
| Model | Dongfeng Cummins QSZ13-C550-Ⅲ |
| Rated power | 410 kw/1900r/min |
| Max. Torque | 2300N.m/1200～1700r/min |
| Displacement | 13L |
| Track width | 450 mm |
| Carrier roller(single side) | 2 pcs |
| Track roller(single side) | 6 pcs |
| Idler(single side) | 1 piece |
| Brake | wet type multi-disc braking device |
| Travel speed | 0-5.5 km/h |
| Max. working pressure | 40 Mpa |
| Control method | electric hydraulic control |
| System flow | 115L/MIN |
| Control way | electric hydraulic control |
| Auger | 6 sets |
| Max. tilling depth | 500mm |
| Tilling width | 2100 mm |
| Max. rotating speed | 506r/min . |
