Crane Accessories
Overview
Crane Accessories supplied by Henan Jinjiayou Trading Co., Ltd. Key published specifications: Surface Black oxide finish; Diameter of runing surface [A] 45 [mm]; Outer diameter with flanges [B] 55 [mm]; Width with flanges [G] 19 [mm]. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Surface | Black oxide finish |
|---|---|
| Diameter of runing surface [A] | 45 [mm] |
| Outer diameter with flanges [B] | 55 [mm] |
| Width with flanges [G] | 19 [mm] |
| Width with hubs [C] | 24 [mm] |
| Width of runing area [D] | 12.3 [mm] |
| Total length with bolt [E] | 65 [mm] |
| Bolt diameter [F] | 12 [mm] |
| Wheel load* max. | 250 [kg] |
| Ball bearing | 1 x 6201 2Z |
| Weight | 0.32 [kg] |
| Recommended rail** | 50 x 12 |
| Mounting Elements | Flat nut M12 with tooth lock washer |
