CoatMaster 6317 insulated bearing for Sensorised traction motor bearing unit
Model 6317/C3VL0241
Overview
CoatMaster 6317 insulated bearing for Sensorised traction motor bearing unit supplied by CoatMaster Bearings Liaocheng ZhuoYi Bearing Co.,Ltd. Key published specifications: Quality Standard 80% service life of SKF; Designation 6317/C3VL0241; Electrical Resistance Voltages Up To 3000 V DC; Cage Brass. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Quality Standard | 80% service life of SKF |
|---|---|
| Designation | 6317/C3VL0241 |
| Electrical Resistance | Voltages Up To 3000 V DC |
| Cage | Brass |
| Cleance | C3 |
| Dimension | 85×180×41 mm |
| Weight | 4.1 kg |
| Factor | Electric Traction Motors |
| Reference speed | 8000r/min |
| Limiting speed | 5000 r/min |
