Anti Corrosion Radial Spherial Plain Bearings GE35ES Gcr15 Black Surface
Model GE35ES
Overview
Anti Corrosion Radial Spherial Plain Bearings GE35ES Gcr15 Black Surface, listed under Roller Bearings by UIB (Xiamen) Bearing CO.,LTD in Xiamen, Fujian. Certification ISO901:2008, bearing material Chrome Steel GCR15, ANSI 52100 and surface treatment Anti Corrosion are among the specifications published.
Technical specifications
| Certification | ISO901:2008 |
|---|---|
| Bearing Material | Chrome Steel GCR15, ANSI 52100 |
| Surface Treatment | Anti Corrosion |
| Dynamic Load | 79 KN |
| Static Load | 399 KN |
| Bearing Weight | 0.228 Kg |
| Bearing Size | 35*55*25mm |
| Other Type Name | GE35ES-2RS |
| ID | 35 Mm |
| Sliding contact surfaces | Steel/Steel |
| Permissible operating temperature range | GE…E:－50℃～＋150℃ |
| material | SUS440. SUS304, Gcr15 |
| Bearing type | Joint Bearing |
| ID. mm | 8 mm |
| length | 36 mm |
| thicknessmm | 10 mm |
| weight | 0.048 kg |
| Boundary Dimensions | 120*180*85 mm |
