Aluminium Alloy Scaffold Tower Custom Modular System Scaffolding Tower
Model GN50
Overview
Aluminium Alloy Scaffold Tower Custom Modular System Scaffolding Tower supplied by GUANGZHOU LEADER EQUIPMENT CO., LTD. Listed under Scaffolding. Key published specifications: Material Aluminum Alloy 6082-T6; Main Tube Tube Wall Thickness: 1.8MM, 3.2MM; Pipe Diameter: 50.8MM; Size(WxL) 0.85m(W)*2.0m/2.5m/3.0m(L); 1.45m(W)*2.0m/2.5m/3.0m(L); Height 2-50m. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Material | Aluminum Alloy 6082-T6 |
|---|---|
| Main Tube | Tube Wall Thickness: 1.8MM, 3.2MM; Pipe Diameter: 50.8MM |
| Size(WxL) | 0.85m(W)*2.0m/2.5m/3.0m(L); 1.45m(W)*2.0m/2.5m/3.0m(L) |
| Height | 2-50m |
| Load Capacity | 200kg/sqm |
| Standard | EN1004;EN12810; EN12811 |
| Type | Rolling Scaffold |
| Thickness | 1.8mm,3.2mm |
| Diameter | 50.8mm |
| Certification | GS & CE |
| Application | Building Construction |
| Tube Wall Thickness | 1.8MM, 3.2MM; Pipe Diameter: 50.8MM |
