3kg/H EPS Extruder Pelletizing Machine with Single Screw
Overview
3kg/H EPS Extruder Pelletizing Machine with Single Screw supplied by Zhangjiagang Friend Machinery Co.,lTD. Listed under Extruders. Key published specifications: Screw Diameter 30 mm; Screw Material 38CrMoAlA; Hardness of Screw HV900-1000; Depth of Nitrogen Treatment 0.4-0.7 mm. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Screw Diameter | 30 mm |
|---|---|
| Screw Material | 38CrMoAlA |
| Hardness of Screw | HV900-1000 |
| Depth of Nitrogen Treatment | 0.4-0.7 mm |
| Screw Straightness | ＜0.015 mm |
| Barrel Material | 38CrMoAlA |
| Barrel inner surface hardness | HV≥940 |
| Main Motor Power | 1.1KW |
| Heating Method | Cast aluminum Heater+ 304stainless steel cover |
| Heating Zones | 3 Periods(Screw Barrel 3periods ) |
| Heating Power | 1.1KW*3=3.3KW |
| Barrel Cooling Method | Forced Air Cooling |
| Screw Maximum Rotating Speed | 0-89 rpm |
| Maximum Capacity | 2Kg/h |
| Screw and Barrel | Zhou shan Jinjiu Screw |
| Gearbox | china brand |
| Breaker | Delix brand |
| Ampere meter | AoYi brand |
| Certification | SGS,UV,CE |
| Application | Plastic Pellet Testing Making |
| Capacity | 1-3kg/h |
| Extruder Type | Single Screw Extruder |
| Motor | Siemens Brand |
| Temperature Controller | Omron Brand |
| Machine technoical parameter | Model No. SJ30 |
| Fan power | 60w*3=0.18kw |
| Certificate | CE, ISO9001.2008. |
