Overview

105 KN Press Steel GCR15 Wheel Hub Unit Bearing 23mm With Taper Rollers supplied by UIB (Xiamen) Bearing CO.,LTD. Listed under Roller Bearings. Key published specifications: Certification TS14909; Weight 0.573kg; Grease Lubricate Speed 4500 (r/min); Oil Lubricate Speed 5600 (r/min). Contact the supplier through the RFQ form for pricing, lead time and full datasheets.

Technical specifications

Certification	TS14909
Weight	0.573kg
Grease Lubricate Speed	4500 (r/min)
Oil Lubricate Speed	5600 (r/min)
Cr	80.8 KN
Cor	105 KN
Bearing Grade	P6, P5 Grade
Bearing type	Taper roller bearing
Roller row	Single
cage material	Press steel
Ring material	GCR15/ AISI52100
Oil hole	NON
Bearing clearance	C3
Bearing weight	0.573kg
Inner diameter	45mm
Bearing applicant	automobile and universal
Outer diameter	85mm
Thickness	23 mm
Heat treatment method	bainite heat treatment
Ball grade	G10
