100kw solar system
Model 360V/100A
Overview
100kw solar system supplied by Iinkpv. Listed under Solar Electric Panels. Key published specifications: Model Type 500W half-cut solar panel; Peak Power(Pmax) 500W; Maximum Power Voltage(Vmp) 41.18V; Maximum Power Current(Imp) 12.14A. Contact the supplier through the RFQ form for pricing, lead time and full datasheets.
Technical specifications
| Model Type | 500W half-cut solar panel |
|---|---|
| Peak Power(Pmax) | 500W |
| Maximum Power Voltage(Vmp) | 41.18V |
| Maximum Power Current(Imp) | 12.14A |
| Open Circuit Voltage(Voc) | 49.42V |
| Short Circuit Current(Isc) | 12.82A |
| Peak Power（20ms) | 300KVA |
| AC Input Voltage Range | 380Vac/400Vac±10%(customized 190Vac/200Vac) |
| Output Wave | Pure sine wave |
| Noise | ≤65dB |
| Elevation | 2000m（More than derating） |
| Installation Method | Tower |
| Humidity | 0%~95% ,No condensation |
| Type | Off-grid with battery back up |
| Output voltage | 220V/380V/400V three phase |
| weight | 25.6KG |
| Size | 2148*1080*35mm Strong anti-cracking advantage |
| Max input voltage | 800V |
| various protection functions; Size | 500*384*228mm |
| Capacity | 2V/1200AH |
| Power | T100kw/360v |
| Low voltage | 324V High voltage:442V, |
| Output | 220V 380V 415V 50/60HZ |
